Terminals

16-14 Ga. Insulated Male-Female .250" Connector

Stock No. 31517 (

3M No. 7100165166) Vinyl Insulated

Stock No. 31717 (

3M No. 7100165165)

Nylon Insulated with extra sleeve

See crimper

Stock No. 428

Tin-plated copper material

MULTI-STUDS

Securely connects to a variety of stud sizes with oblong stud hole and washered face Tin-plated copper material

Wire Ga. Stud Size Stock No. 3M No. Tool Guide

16-14 6-8-10 31758

7100025309

Chart B pg. 22 12-10 6-8-10 32758

7100163832

Pin diameter

PIN TERMINALS

Used to connect wires to terminal strips and trailer connectors Tin-plated copper material

Wire Ga. Pin Dia. Vinyl Nylon Tool Guide Stock No. 3M No. Stock No. 3M No.

22-18 0.075 30585 7100165181 30785 7100165180 Chart B pg. 22 16-14 0.075 31585 7100165199 31785 7100165197 12-10 0.11 32585 7100165201 32785 7100165201

All dimensions in inches

3M MALE-FEMALE QUICK DISCONNECT

Wire Ga. Tab Size Width & Thickness Male - Nylon Female - Nylon Insulation Color

Tool Guide

Stock No. 3M No. with Extra Sleeve Stock No. 3M No. Stock No. 3M No. with Extra Sleeve Stock No. 3M No.

22-18 .187 x .020 30550

7100163898

30750

7000132216

30518

7100163899

30718

7000132217

Red #403 22-18 .250 x .032 30512

7100163888

30712

7100163890

30513

7100163887

30713

7100163889

Red 22-18 .187 x .020 31550

7100163904

31750

7000132219

31518

7000132218

31718

7000132210

Blue 16-14 .250 x .032 31512

7100163880

31712

7100163881

31513

7000132215

31713

7100163810

Blue 12-10 .250 x .032 32514

7100163884

32714

7100163886

32515

7100163883

32715

7100163885

Yellow

All dimensions in inches

3M SCOTCHLOK MALE & FEMALE DISCONNECTS - NYLON INSULATED

Stock No. 30550

Male: Tin-plated copper material

Stock No. 30713

Female: Tin-plated brass material

Used as an in-line connector
